CEEG 1000kVA Dry-Type Transformer

Adopting resin-cast insulation and an oil-free structure, the transformer is suitable for indoor installations and areas with high personnel density. It emphasizes fire safety, environmental protection with zero leakage risk, and low maintenance requirements. Optional natural air cooling or forced air cooling configurations are available to meet different load conditions and continuous operation demands. The 1000 kVA dry-type transformer is a widely used mainstream capacity, offering broad application adaptability with mature installation and maintenance practices, making it a reliable and cost-effective choice for general power distribution needs.

Consult Now

CEEG 1000kVA Dry-Type Transformer - High-Efficiency Cast Resin Transformer for Industrial Power Supply

CEEG 1000kVA Dry-Type Transformer - High-Efficiency Cast Resin Transformer for Industrial Power Supply

CEEG 1000kVA Dry-Type Transformer - High-Efficiency Cast Resin Transformer for Industrial Power Supply

CEEG 1000kVA Dry-Type Transformer - High-Efficiency Cast Resin Transformer for Industrial Power Supply

CEEG 1000kVA Dry-Type Transformer - High-Efficiency Cast Resin Transformer for Industrial Power Supply

CEEG 1000kVA Dry-Type Transformer - High-Efficiency Cast Resin Transformer for Industrial Power Supply

Scope of application

Small & Medium Industrial Facilities

Suitable for small to medium-sized factories and single-building distribution in industrial parks, offering broad applicability and proven reliability.

Small & Medium Industrial Facilities

Mid-Sized Commercial & Office Buildings

Ideal for commercial complexes and office buildings as main transformers or zoned distribution units, with easier installation and maintenance.

Mid-Sized Commercial & Office Buildings

Municipal & Public Buildings

Applicable to municipal power distribution rooms and public infrastructure, ensuring stable and reliable power supply operation.

Municipal & Public Buildings

Product Description

Product Description

1 High Thermal Resistance Insulation System: Combined with DuPont Nomex® and other heat-resistant materials, enabling stable long-term operation under high-temperature and heavy-load conditions.

CEEG 1000kVA Dry-Type Transformer

2 Customized Reliability Design: Can be tailored to specific application environments, ensuring optimal performance, safety, and operational reliability.

CEEG 1000kVA Dry-Type Transformer

3 Stable & Moisture-Resistant Insulation: Epoxy resin insulation offers excellent resistance to humidity and high temperatures, improving operational stability and service life.

CEEG 1000kVA Dry-Type Transformer

4 Robust and Durable Structure: Epoxy resin-cast windings provide strong resistance to short circuits and mechanical impacts, making it suitable for high-humidity and dust-prone environments.

CEEG 1000kVA Dry-Type Transformer

Product Features

Excellent Insulation Performance

Premium Resin Insulation: Utilizes epoxy resin insulation with exceptionally strong dielectric strength, creating a robust barrier against electrical breakdown.
Moisture & Thermal Resistance: Provides superior resistance to moisture ingress and high temperatures, significantly improving overall equipment reliability and long-term durability in harsh environments.

Safe & Reliable

Fire Safety & Leak Elimination: Features an oil-free design with exceptional fire resistance, completely removing the hazards and liabilities of oil leakage.
Extreme Grid Resilience: Engineered to withstand severe short-circuit currents and volatile overvoltage conditions, ensuring stable, reliable operation even in the harshest environments.

Eco-Friendly Design

Eco-Friendly & Non-Toxic: Constructed using completely harmless, non-toxic materials that protect both public health and local ecosystems.
Zero Environmental Risk: Eliminates the need for an oil cooling medium, removing all risks of oil pollution while perfectly aligning with modern energy-saving and environmental standards.

Outstanding Heat Dissipation

Flexible Cooling Versatility: Supports both natural air cooling (AN) and forced air cooling (AF) modes, allowing the system to easily adapt to shifting environmental or load requirements.
Peak Load Optimization: Enhances cooling efficiency during high-demand periods, safely boosting the equipment's capacity output while maintaining rock-solid operational stability.

Robust and Durable Structure

Structural Integrity & Fault Defense: Features an optimized coil and core structure meticulously engineered to withstand intense electromagnetic forces during sudden short-circuit events.
Continuous Heavy-Duty Output: Built with rugged thermal and mechanical endurance, making it perfectly suited for long-term, continuous operation under high-stress conditions.

Easy and Hassle-Free Maintenance

Streamlined Maintenance & Inspection: Features an oil-free design that eliminates the need for routine oil-level checks, fluid sampling, and dissolved gas analysis (DGA), significantly reducing daily maintenance labor.
Rapid Fault Isolation & Low Downtime: Enables faster, more straightforward fault localization to accelerate troubleshooting, drastically reducing overall maintenance workload and operational downtime risks.

Main Parameters

Rated Voltage	6 kV, 10 kV, 35 kV and other standard voltage levels
Capacity Range	50 kVA – 2500 kVA
Cooling Method	Natural air cooling (AN) / Forced air cooling (AF)
Insulation Class	Class F / Class H

Implementation Standard

Implementation Standard

GB/T 6451-2015 Technical Specifications for Power Transformers

GB 1094.1-2013 Power Transformers Part 1: General Requirements

GB/T 10228-2015 Technical Parameters and Requirements for Dry-Type Power Transformers

JB/T 10393-2002 Technical Conditions for Dry-Type Transformers

ISO 9001 Quality Management System Certification

Technical Advantages

R&D Cloud Platform

R&D Cloud Platform

An integrated digital platform combining electromagnetic optimization design, parametric modeling, performance analysis, structural optimization, and automatic drawing generation. It enables transformer design resource sharing and efficient data management, including search, modification, and version control.

Simulation Analysis

Simulation Analysis

Comprehensive multi-physics simulation covering fluid flow, thermal field, electric field, leakage magnetic field, transient processes, and short-circuit forces. Each transformer series is optimized through thermal and flow analysis to accurately control winding temperature rise and hotspot distribution, ensuring reliable and stable performance.

Smart Operation & Maintenance Platform

Smart Operation & Maintenance Platform

By collecting key data such as temperature, current, voltage, vibration, and grid harmonics, the system enables real-time power quality analysis and fault alarms. It also supports mobile access for remote monitoring and intelligent O&M management.
