CEEG IDC Smart Integrated Power Module - All-in-One Data Center Power Supply Solution with High Efficiency
Certification
CE
CNAS
ISO
KEMA
TUV
UL
Home  >  Products  >  Integrated Power System  >  CEEG IDC Smart Integrated Power Module
CEEG IDC Smart Integrated Power Module
The IDC intelligent integrated power module combines a Grade 1 energy-efficient amorphous alloy transformer, power distribution modules, and intelligent terminals into one system. Through a centralized design, it reduces line losses and construction costs. It supports modular configuration, prefabricated delivery, and visualized operation and maintenance, helping to shorten the overall project construction cycle.
Consult Now Consult Now 1899-414-7812
CEEG IDC Smart Integrated Power Module - All-in-One Data Center Power Supply Solution with High Efficiency
CEEG IDC Smart Integrated Power Module - All-in-One Data Center Power Supply Solution with High Efficiency
CEEG IDC Smart Integrated Power Module - All-in-One Data Center Power Supply Solution with High Efficiency
CEEG IDC Smart Integrated Power Module - All-in-One Data Center Power Supply Solution with High Efficiency
CEEG IDC Smart Integrated Power Module - All-in-One Data Center Power Supply Solution with High Efficiency
CEEG IDC Smart Integrated Power Module - All-in-One Data Center Power Supply Solution with High Efficiency
prev
next
Scope of application
Data Centers
Power supply and distribution for computing facilities and data center campuses, focusing on low line loss, modular design, and fast deployment
Data Centers
Industrial Park Energy Systems
Energy centers for large industrial parks, emphasizing integration and visualized operation and maintenance
Industrial Park Energy Systems
Smart Upgrades
New construction or retrofit projects, focusing on shorter construction cycles and scalability
Smart Upgrades
Product Description
Product Description
1 Transformer: Amorphous alloy Grade 1 energy-efficient transformer with patented semi-encapsulated three-phase three-column design, significantly reducing no-load loss
CEEG IDC Smart Integrated Power Module
2 Incoming Cabinet: Controls the power flow from the transformer’s low-voltage side to the main low-voltage distribution cabinet
CEEG IDC Smart Integrated Power Module
3 Bus Coupler Cabinet: Connects two main busbars and controls their switching
CEEG IDC Smart Integrated Power Module
4 SVG/APF: Reactive power and harmonic compensation, improving system stability and efficiency while enhancing power factor
CEEG IDC Smart Integrated Power Module
5 UPS: Supports modular or tower-type UPS system configurations
CEEG IDC Smart Integrated Power Module
6 Maintenance Bypass Cabinet: Provides an alternative power path during UPS maintenance or failure, ensuring continuous load operation
CEEG IDC Smart Integrated Power Module
Product Features
CEEG IDC Smart Integrated Power Module

Space Saving

  • Compact Design: High-density integration saves ~50% of available space.
  • Space-Optimized: Ideal for tight, space-limited environments.
CEEG IDC Smart Integrated Power Module

Cost Reduction

  • Eco-Efficient: Optimized energy flow reduces losses by ~30%.
  • Cost-Effective: Minimizes operational waste to boost economic efficiency.
CEEG IDC Smart Integrated Power Module

Energy Saving

  • Grade 1 Efficiency: Amorphous transformer maximizes energy savings.
  • High Savings: Saves ~11,000 kWh/year (based on 2500 kVA).
CEEG IDC Smart Integrated Power Module

High Reliability

  • Hot-Swappable Modules: Modular design allows online maintenance without shutdown, minimizing downtime.
  • Centralized Bypass: Enhances system reliability to ensure a continuous, stable power supply.
CEEG IDC Smart Integrated Power Module

Fast Deployment

  • Plug-and-Play: Factory pre-assembly enables fast on-site installation.
  • Rapid Delivery: Prefabrication significantly shortens the overall delivery time.
CEEG IDC Smart Integrated Power Module

Easy Operation & Maintenance

  • Smart Monitoring: Centralized tracking and alarm linkage enable fast fault location.
  • Efficient O&M: Speedier troubleshooting significantly improves maintenance efficiency.
Main Parameters
Transformer Input 10kv AC 50/60Hz
Transformer Capacity 1.25MVA- 2.5MVA
Feeder Cabinet Switch Capacity 630A、 400A、 250A、 160A、 100A
Low-Voltage Cabinet Fixed type / Withdrawable type
Overall Cabinet Dimensions 2475*9600/10200*1500mm， 可定制
Operating Temperature -5~40℃
Implementation Standard
Implementation Standard
GB/T 19939-2005 Technical requirements for power transformers
GB/T 18655-2010 General technical requirements for power system automation devices
IEC 62040 Series Uninterruptible power systems (UPS)
ISO 50001:2018 Energy management systems
UL 60950-1 Safety requirements for information technology equipment
Technical Advantages
Smart Terminal
Smart Terminal
An integrated sensing and communication device with simple installation and reduced wiring requirements.
Customer Display Screen
Customer Display Screen
A centralized, visualized, and intelligent management center for transformers.
AI Safety Operation Model
AI Safety Operation Model
Uses big data analytics to identify potential risks in advance and enable predictive fault detection.
