CEEG SCB11 Dry-Type Transformer

Adopting resin-cast insulation and an oil-free structure, the transformer is suitable for indoor installations and areas with high personnel density. It emphasizes fire safety, environmental protection with zero leakage risk, and low maintenance requirements. Optional natural air cooling or forced air cooling configurations are available to meet different load conditions and continuous operation demands. The SCB11 dry-type transformer is a mainstream upgraded model with a stronger focus on loss reduction and temperature rise control, offering a more balanced overall cost-performance ratio.

Consult Now

CEEG SCB11 Dry-Type Transformer - Energy-Efficient Cast Resin Transformer with Reduced No-Load Loss

CEEG SCB11 Dry-Type Transformer - Energy-Efficient Cast Resin Transformer with Reduced No-Load Loss

CEEG SCB11 Dry-Type Transformer - Energy-Efficient Cast Resin Transformer with Reduced No-Load Loss

CEEG SCB11 Dry-Type Transformer - Energy-Efficient Cast Resin Transformer with Reduced No-Load Loss

CEEG SCB11 Dry-Type Transformer - Energy-Efficient Cast Resin Transformer with Reduced No-Load Loss

CEEG SCB11 Dry-Type Transformer - Energy-Efficient Cast Resin Transformer with Reduced No-Load Loss

Scope of application

General Industrial Plants & Distribution Rooms

Suitable for standard workshops and general-purpose power distribution rooms, meeting basic and conventional load requirements.

General Industrial Plants & Distribution Rooms

Commercial MEP Back-of-House Facilities

Ideal for mechanical and electrical rooms in commercial complexes and property management distribution areas, balancing installation convenience and maintenance efficiency.

Commercial MEP Back-of-House Facilities

Public Building Power Distribution

Applicable to schools, residential communities, and similar public infrastructure, emphasizing operational safety and stable performance.

Public Building Power Distribution

Product Description

Product Description

1 High-Quality Core Material: Made of premium high-permeability silicon steel with full mitered joints and multi-step step-lap process, ensuring low no-load losses and improved energy efficiency.

CEEG SCB11 Dry-Type Transformer

2 Low Noise Design: Nano-coating self-leveling surface treatment effectively reduces operating noise for quieter performance.

CEEG SCB11 Dry-Type Transformer

3 High Safety & Reliability: Strong waterproof performance, excellent short-circuit withstand capability, high overload capacity, and stable electrical performance ensure safe and reliable operation.

CEEG SCB11 Dry-Type Transformer

4 Advanced Engineering Validation: Optimized through electric field, thermal field, and magnetic field simulation analysis, and among the earliest in China to pass KEMA E2, C2, and F1 type tests.

CEEG SCB11 Dry-Type Transformer

Product Features

Insulation Material

Premium Resin Insulation: Adopts an integral epoxy resin casting process, providing exceptional insulation performance and advanced moisture resistance.
High-Temperature Endurance: Engineered to reliably withstand severe thermal stress, ensuring long-term stable and reliable transformer operation under demanding conditions.

Safe & Reliable

Superior Fire Resistance: Features an inherently safe, oil-free design that provides excellent fire resistance, eliminating the risk of catastrophic fire hazards.
Zero Leakage & Pollution: Completely removes the risk of fluid leakage, ensuring zero environmental pollution concerns while dramatically increasing overall operational safety.

Eco-Friendly Design

Eco-Friendly & Non-Toxic: Utilizes strictly environmentally friendly, non-toxic materials that pose no risk to operators or surrounding ecosystems.
Zero Oil Contamination: Eliminates the need for oil cooling entirely, preventing fluid leaks and spills while fully meeting modern energy-saving and environmental protection requirements.

Excellent Heat Dissipation

Flexible Cooling Options: Supports both natural air cooling (AN) and forced air cooling (AF) to adapt seamlessly to varying environmental and operational demands.
Peak Load Boost: Allows for the application of forced air cooling under heavy load conditions, safely increasing the transformer's output capacity while maintaining stable thermal levels.

Robust and Durable Structure

Enhanced Short-Circuit Resilience: Features an optimized coil and core structure engineered with superior short-circuit withstand capability to safely absorb sudden electrical surges.
Continuous Heavy-Duty Operation: Built for rugged endurance, making it perfectly suited to handle long-term, continuous operating conditions without compromising system reliability.

Easy and Hassle-Free Maintenance

Simplified Daily Maintenance: Features an oil-free design that eliminates complex fluid testing and monitoring, significantly reducing daily inspection workload.
Minimized Downtime Risk: Enables faster, more straightforward fault localization, streamlining troubleshooting to keep operational downtime to an absolute minimum.

Main Parameters

Rated Voltage	6 kV, 10 kV, 35 kV and other standard voltage levels
Capacity Range	50 kVA – 2500 kVA
Cooling Method	Natural air cooling (AN) / Forced air cooling (AF)
Insulation Class	Class F / Class H

Implementation Standard

Implementation Standard

GB/T 6451-2015 Technical Specifications for Power Transformers

GB 1094.1-2013 Power Transformers Part 1: General Rules

GB 1094.11 Insulation Levels and Voltage Tests for Dry-Type Transformers

IEC 60076 Power Transformers Standard

ISO 9001 Quality Management System Certification

Technical Advantages

R&D Cloud Platform

R&D Cloud Platform

An integrated digital platform combining electromagnetic optimization design, parametric modeling, performance analysis, structural optimization, and automatic drawing generation. It enables transformer design resource sharing and efficient data management, including search, modification, and version control.

Simulation Analysis

Simulation Analysis

Comprehensive multi-physics simulation covering fluid flow, thermal field, electric field, leakage magnetic field, transient processes, and short-circuit forces. Each transformer series is optimized through thermal and flow analysis to accurately control winding temperature rise and hotspot distribution, ensuring reliable and stable performance.

Smart Operation & Maintenance Platform

Smart Operation & Maintenance Platform

By collecting key data such as temperature, current, voltage, vibration, and grid harmonics, the system enables real-time power quality analysis and fault alarms. It also supports mobile access for remote monitoring and intelligent O&M management.
