CEEG SCB12 Dry-Type Transformer

Adopting resin-cast insulation and an oil-free structure, the transformer is well-suited for indoor installations and areas with high personnel density. It emphasizes fire safety, environmental protection with zero leakage risk, and low maintenance requirements. Optional natural air cooling or forced air cooling configurations are available to meet different load conditions and continuous operation demands. The SCB12 dry-type transformer features further optimized energy efficiency and operational performance, making it ideal for projects where electricity cost and total lifecycle cost are key considerations.

Consult Now

CEEG SCB12 Dry-Type Transformer - Low-Loss Cast Resin Transformer for High-Efficiency Power Distribution

CEEG SCB12 Dry-Type Transformer - Low-Loss Cast Resin Transformer for High-Efficiency Power Distribution

CEEG SCB12 Dry-Type Transformer - Low-Loss Cast Resin Transformer for High-Efficiency Power Distribution

CEEG SCB12 Dry-Type Transformer - Low-Loss Cast Resin Transformer for High-Efficiency Power Distribution

CEEG SCB12 Dry-Type Transformer - Low-Loss Cast Resin Transformer for High-Efficiency Power Distribution

CEEG SCB12 Dry-Type Transformer - Low-Loss Cast Resin Transformer for High-Efficiency Power Distribution

Scope of application

High-Duty Industrial Users

Suitable for manufacturing production lines and other high-load-rate applications, with a focus on reducing operating electricity costs and optimizing lifecycle cost efficiency.

High-Duty Industrial Users

Urban Power Distribution Retrofit

Ideal for retrofit and upgrade projects of existing distribution systems, emphasizing stable operating performance and maintenance-friendly design.

Urban Power Distribution Retrofit

Indoor, Eco-Friendly & Noise-Sensitive Environments

Applicable to indoor substations and distribution rooms where low noise levels and environmental compatibility are critical requirements.

Indoor, Eco-Friendly & Noise-Sensitive Environments

Product Description

Product Description

1 High-Quality Core Material: Made of premium high-permeability silicon steel with full mitered joints and multi-step step-lap process, ensuring low no-load loss and improved energy efficiency.

CEEG SCB12 Dry-Type Transformer

2 Low Noise Design: Nano-coating self-leveling surface treatment effectively reduces operational noise for quieter performance.

CEEG SCB12 Dry-Type Transformer

3 High Safety & Reliability: Strong waterproof performance, excellent short-circuit withstand capability, high overload capacity, and stable electrical performance ensure safe and reliable operation.

CEEG SCB12 Dry-Type Transformer

4 Advanced Engineering Validation: Optimized through electric field, thermal field, and magnetic field simulation analysis, and among the earliest in China to pass KEMA E2, C2, and F1 type tests.

CEEG SCB12 Dry-Type Transformer

5 Dual-Mode Structural Design: Flexible dual-configuration options to meet diverse customer requirements and application scenarios.

CEEG SCB12 Dry-Type Transformer

6 Smart Transformer Solution: Equipped with proprietary intelligent transformer system with big data cloud diagnostics for real-time online monitoring and intelligent operation & maintenance.

CEEG SCB12 Dry-Type Transformer

Product Features

Safe & Reliable

Superior Fire Resistance: Inherently safe design provides exceptional fire resistance, entirely eliminating fire hazards in sensitive or high-risk environments.
Eco-Friendly & Leak-Free: The oil-free engineering completely removes the risk of fluid leakage, eliminating associated environmental pollution and contamination hazards.

Eco-Friendly Design

Zero Oil Pollution Risk: Requires no oil cooling medium, entirely eliminating the risk of hazardous leaks and spills.
Eco-Friendly & Energy-Efficient: Designed to perfectly align with strict environmental protection regulations and modern energy-saving requirements.

Excellent Heat Dissipation

Boosted Capacity Output: Allows for the seamless application of forced air cooling during heavy load periods, safely increasing the transformer's overall capacity output.
Stable High-Load Performance: Effectively manages thermal dissipation during peak demand, ensuring continuous, stable performance when the system is under maximum stress.

Multi-Dimensional Temperature Control

Comprehensive Thermal Monitoring: Incorporates an innovative 7-level temperature control technology that delivers precise, comprehensive monitoring of operating temperatures across critical zones.
Optimized Dissipation & Stability: Significantly improves heat dissipation efficiency, protecting vital components and ensuring long-term, stable, and reliable operation.

Robust and Durable Structure

Enhanced Short-Circuit Resilience: Features an optimized coil and core structure engineered with superior short-circuit withstand capability to safely absorb sudden electrical surges.
Continuous Heavy-Duty Operation: Built for rugged endurance, making it perfectly suited to handle long-term, continuous operating conditions without compromising system reliability.

Easy and Hassle-Free Maintenance

Simplified Daily Maintenance: Features an oil-free design that eliminates complex fluid testing and monitoring, significantly reducing daily inspection workload.
Minimized Downtime Risk: Enables faster, more straightforward fault localization, streamlining troubleshooting to keep operational downtime to an absolute minimum.

Main Parameters

Rated Voltage	6 kV, 10 kV, 35 kV and other standard voltage levels.
Capacity Range	50 kVA – 2500 kVA
Cooling Method	Natural air cooling (AN) / Forced air cooling (AF)
Insulation Class	Class F / Class H

Implementation Standard

Implementation Standard

GB/T 6451-2015 Technical Specifications for Power Transformers

GB/T 10228-2015 Technical Parameters and Requirements for Dry-Type Power Transformers

GB 1094.1-2013 Power Transformers Part 1: General Requirements

IEC 60076 Power Transformers

JB/T 10393-2002 Technical Conditions for Dry-Type Transformers

Technical Advantages

R&D Cloud Platform

R&D Cloud Platform

An integrated digital platform combining electromagnetic optimization design, parametric modeling, performance analysis, structural optimization, and automatic drawing generation. It enables transformer design resource sharing and efficient data management, including search, modification, and version control.

Simulation Analysis

Simulation Analysis

Comprehensive multi-physics simulation covering fluid flow, thermal field, electric field, leakage magnetic field, transient processes, and short-circuit forces. Each transformer series is optimized through thermal and flow analysis to accurately control winding temperature rise and hotspot distribution, ensuring reliable and stable performance.

Smart Operation & Maintenance Platform

Smart Operation & Maintenance Platform

By collecting key data such as temperature, current, voltage, vibration, and grid harmonics, the system enables real-time power quality analysis and fault alarms. It also supports mobile access for remote monitoring and intelligent O&M management.
