CEEG SCB18 Dry-Type Transformer

Adopting resin-cast insulation and oil-free construction, the transformer is suitable for indoor installations and areas with high personnel density. It emphasizes fire safety, environmental friendliness with no leakage risk, and low maintenance requirements. Optional natural air cooling or forced air cooling solutions are available to meet different load conditions and continuous operation demands. The SCB18 series dry-type transformer features ultra-high energy efficiency and enhanced reliability design, targeting stricter energy consumption standards and higher stability requirements, making it ideal for critical load applications.

Consult Now

180-1334-5718

Scope of application

Critical Continuous Loads

Suitable for data centers and computing power parks, with a focus on high reliability and ultra-high energy efficiency performance.

Key Transportation Hubs

Applied in airports, rail transit hubs, and core commercial complexes, meeting stringent requirements for critical power supply continuity and stability.

Power Quality-Sensitive Industries

Ideal for high-end manufacturing, semiconductor, and precision production environments, where high power quality and operational stability are essential.

Product Description

1 High-Quality Core Material: Made with premium high-permeability silicon steel, full mitered joints and multi-step lamination process, resulting in low no-load loss and improved efficiency.

2 Low Noise Design: Nano-level self-leveling coating technology is applied on the surface, effectively reducing operating noise for quieter performance.

3 Strong Safety & Reliability: Excellent waterproof performance, strong short-circuit withstand capability, high overload capacity, and stable electrical performance ensure safe and reliable operation.

4 Advanced Engineering Validation: Optimized through electric field, thermal field, and magnetic field simulation analysis, and among the first in China to pass KEMA E2, C2, and F1 type tests.

5 Dual-Mode Structural Design: Supports dual configuration options to meet the diverse requirements of different customer segments.

6 Smart Transformer Solution: Equipped with intelligent transformer technology and big data cloud-based diagnostics for real-time online monitoring and predictive maintenance.

Product Features

Insulation Material

The transformer windings adopt epoxy resin integral casting, providing excellent insulation performance, moisture resistance, and high-temperature endurance.

Safe & Reliable

The SCB series dry-type transformer offers excellent fire resistance, is oil-free, and eliminates the risk of oil leakage, environmental pollution, and fire hazards.

Excellent Heat Dissipation

When operating under heavy load, forced air cooling can be applied to increase transformer capacity output and ensure stable performance.

Eco-Friendly Design

Using epoxy resin insulation, the product is environmentally friendly, non-toxic, and harmless. No oil cooling medium is required, eliminating the risk of oil pollution and meeting environmental protection and energy-saving requirements.

Robust and Durable Structure

Optimized coil and core structure with enhanced short-circuit withstand capability, suitable for long-term continuous operation conditions.

Easy and Hassle-Free Maintenance

Oil-free design simplifies daily inspection and maintenance, enables easier fault localization, and reduces maintenance workload and downtime risk.

Implementation Standard

GB/T 6451-2015 Technical Specifications for Power Transformers

GB 1094.1-2013 Power Transformers Part 1: General Requirements

IEC 60076 Power Transformers

JB/T 10393-2002 Technical Conditions for Dry-Type Transformers

ISO 9001 Quality Management System Certification

Technical Advantages

R&D Cloud Platform

An integrated digital platform combining electromagnetic optimization design, parametric modeling, performance analysis, structural optimization, and automatic drawing generation. It enables transformer design resource sharing and efficient data management, including search, modification, and version control.

Simulation Analysis

Comprehensive multi-physics simulation covering fluid flow, thermal field, electric field, leakage magnetic field, transient processes, and short-circuit forces. Each transformer series is optimized through thermal and flow analysis to accurately control winding temperature rise and hotspot distribution, ensuring reliable and stable performance.

Smart Operation & Maintenance Platform

By collecting key data such as temperature, current, voltage, vibration, and grid harmonics, the system enables real-time power quality analysis and fault alarms. It also supports mobile access for remote monitoring and intelligent O&M management.

Rated Voltage	6 kV, 10 kV, 35 kV and other standard voltage levels
Capacity Range	50 kVA – 2500 kVA
Cooling Method	Natural air cooling (AN) and forced air cooling (AF)
Insulation Class	Class F or Class H
